| Battery System Side | |
|---|---|
| Model | HV-768V 280AH*3P |
| Rated voltage | 768V |
| Rated capacity | 840ah(0.2C) |
| Charge voltage | 852VDC(adjustable) |
| Discharge voltage | 672VDC |
| Rated working current | 300A(0.35C) |
| Max.working current | 420A(0.5C) |
| Rated power | 252KW |
| Max.output power | 322KW |
| Recommended DoD | 90% |
| Range of working temp | -10~50°C |
| Working humidity range | 5-85%RH |
| Communication method | two way CAN2.0/RS485 |
| Working indicator | Blue:Power; Green:Running; Red:Alarm protection |
| Cycle life | 25±2°C, 0.2C/0.2C, EOL70%≥6000 |
| Display method | 10inch(LCD)/PC Software |
| Protective function |
Voltage protection: Over charge and over discharge Temperature protection: Over temperature range protection Current/Leakage protection: YES Dielectric withstand voltage: 1000VDC(not less than 1 GΩ) |
| Dimension | 20 feet container |
| Protection level | IP65 |
| Product packaging | Container |
| PCS DC Input Side | |
|---|---|
| Voltage | 420-850VDC(768V) |
| Max.charge power | - |
| Max.discharge current | 250KW |
| PCS-PV Input Side | |
| Max.photovoltaic power | 360KW |
| Max.photovoltaic voltage | 1000V |
| Starting voltage | 150V |
| MPPT range | 250-850VDC |
| Full load DC voltage | 450-850VDC |
| Rated DC input | 600V |
| PV input current | single way 36A |
| PV input channels | 10 ways |
| Communication method | two way CAN2.0/RS485 |
| PCS-AC output side(Off-grid) | |
| Rated AC power | 275KVA |
| Active power | 250KW |
| Rated voltage | 400VAC |
| Rated current | 361A |
| THDU | <2% linear |
| Rated frequency | 50/60Hz |
| Overload capacity | 110% long-term |
| PCS—AC side(On-grid) | |
| Rated AC power | 275KVA |
| Active power | 100KW |
| Rated voltage | 250KW |
| Rated current | 361A |
| Voltage range | 320-460VAC |
| Rated frequency | 50/60Hz |
| THDU | <3% linear |
| Power factor | Standard:1.0; lead 0.8/lag 0.8 |
| AC Phase | Three-phase four-wire+ground wire(3W+N+PE) |
| Isolation transformer | 0.68% |
| Grid certification | TUV, CE |
| Working temp.range | -40~60°C, >45°C Power down |
| Communication method | RS485/CAN |
