| Rated Power (kW) | 1250 |
| Rated Grid Voltage (V) | 3W+N+PE, 380V/400V |
| Rated Grid Frequency (Hz) | 50Hz/60Hz |
| Overload Capacity | 105%: Long-time Running; (105%~120%): 10min; >120%: 1min |
| Cell Type | LFP |
| Battery System Power (KWh) | 2411.25 |
| Cycle Life | 6000 cycles (0.5C @ 25°C Charge/Discharge @ 90% DOD, EOL 80%) |
| Isolation Method | Isolation Transformer (built-in) |
| Grid connection | Hybrid grid |
| NO/OFF Grid Switch Device | STS (Optional) |
| Grid Monitor | YES |
| Surge Protection | YES |
| Fire Fighting System | YES |
| OEM/ODM | Support Customization |
| BMS | Built-in BMS Protection |
| IP Class | Outdoor IP54 |
| Working Temperature Range | -20°C ~ 55°C (Derated above 45°C) |
| Relative Humidity | 0%RH ~ 95%RH, Non-condensing |
| Max. Working Altitude (m) | 2000m (2000m ~ 4000m Derate) |
| Display | Touchscreen |
| Cooling | Air Cooling |
| Communication Interface | RS485, LAN |
| Communication Protocol | Modbus-RTU, Modbus-TCP |
| Certificate | IEC62933, IEC62477, IEC61000, G99, VDE4110, EN50549-1, EN50549-2, UN3536 |
