| Model | GE-F60 |
| Cell Chemistry | LiFePO4 |
| Module Energy (kWh) | 5.12 |
| Module Nominal Voltage (V) | 51.2 |
| Module Capacity (Ah) | 100 |
| Battery Module Qty In Series (Optional) | 12 |
| System Nominal Voltage (V) | 614.4 |
| System Operating Voltage (V) | 480 ~ 700 |
| System Energy (kWh) | 61.44 |
| System Usable Energy (kWh) | 55.29 |
| Rated DC Power | 61.44 |
| Recommended Charge/Discharge Current (A) | 50 |
| Nominal Charge/Discharge Current (A) | 100 |
| Peak Discharge Current (2 mins, 25°C) | 125 |
| Working Temperature (°C) | Charge: 0 ~ 55 / Discharge: -20 ~ 55 |
| Status Indicator | Yellow: Battery High Voltage Power On | Red: Battery System Alarm |
| Communication Port | CAN2.0 / RS485 |
| Humidity | 5% ~ 85% RH |
| Altitude | ≤ 2000m |
| IP Rating of Enclosure | IP55 |
| Dimension (W/D/H, mm) | 780 * 1056 * 2235 |
| Weight Approximate (kg) | 1.2T |
| Installation Location | Floor-mounted |
| Storage Temperature (°C) | 0 ~ 35 |
| Recommend Depth of Discharge | 90% |
| Cycle Life | 25±2°C, 0.5C/0.5C, EOL70% ≥ 6000 |
| Warranty | 10 years |
| Certification | CE, IEC62619, IEC62040, UN38.3 |
