| Model | OceanStor Dorado 5000 V6 | OceanStor Dorado 6000 V6 |
|---|---|---|
| Hardware Specifications | ||
| Maximum Number of Controllers | 32* | 32* |
| System Cache | 256 GB–8 TB | 1–24 TB* |
| Supported Interface Protocols | FC, iSCSI, NFS, CIFS, FC-NVMe, NVMe over RoCE, NDMP, S3*, NFS over RDMA | |
| Front-End Port Types | 8/16/32/64 Gbit/s FC/FC-NVMe and 10/25/40/100 Gbps Ethernet, 25/100Gbps NVMe over RoCE/NFS over RDMA | |
| Back-End Port Types | 100G RDMA/SAS 3.0 | |
| Maximum Number of Hot-Swappable I/O Modules per Controller Enclosure | 12 | 12 |
| Maximum Number of Front-End Ports per Controller Enclosure | 48 | 48 |
| Maximum Number of SSDs | 3200 | 4800 |
| Supported SSDs | 1.92TB/3.84TB/7.68TB/15.36TB/30.72TB palm-sized NVMe SSD 960GB/1.92TB/3.84TB/7.68TB SAS SSD 3.84TB/7.68TB/15.36TB/30.72TB palm-sized, encrypted NVMe SSD 7.68TB/15.36TB/30.72TB Capacity-optimized NVMe SSD and encrypted NVMe SSD |
|
| Number of LUNs | 16,384 | 32,768 |
| Supported SCM | 800GB/1.6TB* | |
| Software Specifications | ||
| Supported RAID Levels | RAID 5, RAID 6, RAID 10*, and RAID-TP (tolerates simultaneous failure of 3 SSDs) | |
| Value-Added Features | SmartDedupe, SmartCompression, SmartVirtualization, SmartMigration, SmartQos(SAN&NAS), SmartThin, SmartQuota(NAS), SmartMulti-Tenant(SAN&NAS), SmartCache, SmartTier, SmartMigration for NAS, SmartMobility*, SmartMove(NAS) HyperSnap(SAN&NAS), HyperClone(SAN&NAS), HyperCDP(SAN&NAS), HyperReplication(SAN&NAS), HyperMetro(SAN&NAS), HyperLock(NAS), HyperDetect(NAS)*, HyperEncryption(SAN&NAS), HyperLink(SAN&NAS), CloudBackup(NAS)*, CloudVxLAN(NAS), HyperDetect for SAN* |
|
| Storage Management Software | DeviceManager, UltraPath, NFS+ and DME IQ | |
Powered by multi-core processors to handle intensive workloads and maximize efficiency.
Flexible and high-density storage options to meet evolving business needs.
Intelligent automation and analytics ensure streamlined operations and reduced downtime.
Robust protection to safeguard critical data and ensure compliance with industry standards.
Eco-friendly design with optimized power consumption for sustainable IT infrastructure.
Yes. We support on-demand customization, including customized colors, customized appearance size, and logo customization configured to your specifications.
We support payment methods such as T/T, Western Union, PayPal, cash, and other terms based on negotiation.
We usually coordinate the most appropriate transportation method (sea, air, or land) according to the cargo conditions and your specific delivery requirements.
You can send your detailed hardware requirements and reference information. We will customize a configuration scheme based on your needs and provide you with a specific pricing structure.
These systems support RAID 5, RAID 6, RAID 10*, and RAID-TP (which tolerates the simultaneous failure of up to 3 SSDs).
They offer Hybrid Storage (combining HDDs and SSDs) with storage capacities exceeding 1TB, powered by Intel Xeon processors.
