| Project | Parameter Item | Specifications |
|---|---|---|
| System Parameter | Rated line voltage | AC380+20% |
| Electrical wiring | Three phase three wire / three phase four wire | |
| Take electric wires | C-phase line / DC bus (customizable) | |
| Grid frequency | 50Hz/60Hz | |
| Circuit topology | Three phase three-level | |
| Full response time | Compensated reactive power: <5ms; Full compensation: <15ms | |
| Reactive power compensation | -1~1 adjustable | |
| Correction rate of three-phase imbalance | 100% | |
| Harmonic filtering rate | >97% | |
| Overall efficiency | >97.5% | |
| Switching frequency | 50khz | |
| Cooling method | Intelligent air cooling / forced air cooling / T-type natural air cooling | |
| Noise | <60dB@1m / <50dB@1m (T-shaped) | |
| Installation method | Module, rack, cabinet, wall mounted, box mounted | |
| Exterior | Colour | Aluminum zinc coated board, white, black, gold primary colors, etc. (customizable) |
| Communication Monitoring | Communication interface | Supported |
| Communication protocol | Supported | |
| Fault alarm | Supported | |
| Background monitoring | Supported | |
| On site display | Supported | |
| Environmental Requirements | Ambient temperature | -20°C~+50°C |
| Relative humidity | ≤90% RH without condensation | |
| Installation altitude | ≤ 2000m rated capacity, > 2000m reduced capacity operation | |
| Protection level | Standard Industry Level |
